HPS cone crusher
Tel: +86-21-68768882
Email: info@shwlm.com
Video
  • Features
  • Technique Data
  • Service
The HPS cone crusher is characterized by a combination of large crushing force, large eccentricity, high crushing frequency and crushing cavity design, which not only improves the production capacity and product quality, but also expands the application range. Whether for medium, fine or superfine crushing, you can find the best solution from the HPS series multi-cylinder hydraulic cone crushers.

Product advantages
• Advanced design and superior performance---to improve long-term efficient production ability.
• Excellent material and workmanship---to improve equipment quality, reduce operating costs and risks.
• Intelligent control, laminating crushing---to increase crushing fineness and crushing efficiency
• Hydraulic clearing, modular components---to ensure high equipment operation rate, low maintenance cost and easy maintenance.
Specifications

Model Luminal
Max.feed size
(mm)
Min.feed size
(mm)
Speed
(rpm)
Power
（KW）
Weight
（t）
HPS100 C 135 16 800 75-112 6.8
F 105 16 800 75-112 6.8
HPS200 C 185 19 800 110-150 12
F 145 17 800 110-150 12
S 70 13 800 110-150 12
HPS300 C 210 22 750 180-250 18.7
F 185 19 750 180-250 18.7
S 90 16 750 180-250 18.7
HPS400 C 290 25 750 220-300 28.4
F 210 22 750 220-300 28.4
S 110 16 750 220-300 28.4



Capacity

Model
The Capacity (TPH) of different Discharge size(mm)

13 16 19 22 25 32 38 45 51
HPS100   75-85 80-95 85-100 90-110 100-130
  55-70 65-80 70-85 75-95 90-110
HPS200       180-210 200-240 235-270 265-310
    145-165 165-195 185-220 210-245 230-280
90-110 105-125 120-135 125-140 130-150 140-165
HPS300       210-240 230-280 270-320 290-350 320-380 360-430
    190-220 205-230 225-260 245-285 270-330 300-350
  135-155 150-170 165-185 180-200 200-220
HPS400         295-355 335-375 370-480 430-500 470-550
      265-310 290-330 315-360 350-410 390-440
  155-185 175-200 195-225 210-245 235-256

NOTE: The specifications above are for reference only; for more configurations, please consult our sales staff.


  •  Agency and agent all ovr the world
    White Lai have many office in main market , and services to the customers face-to-face.
  •  Wear parts supply whole year
    White Lai with most professional wear parts supply system,to meet the market demand for services effectively.
  •  The top services to you
    White Lai's after-service number is 0086-21-68768882, 24 hours technical support by e-mail, by phone.
  •  The first-class customer service
    If needed,experienced technicians guidance is available anytime.
  •  Technical support whole day
    White Lai has service team , guidence with maintenance , spare parts , technical service work ,ect.
